Motorized Ultra Precise Stereotaxic Instruments

Ultra Precise Motorized Stereotaxic Instruments with 10-micron Resolution (10µm movement).

Item Product Price QTY
51730M Motorized Just for Mouse Stereotaxic Inst. w/Joystick Login
51600M Motorized Lab Standard Stereotaxic, Rat w/Joystick Login
51500M Motorized New Standard Stereotaxic, Rat and Mouse w/Joystick Login
52702 Joystick for Motorized Control Box Login
51555M Micromotor Drill w/LED Lights & Bits (Motorized & QSI only) Login
53800 Stoelting Rodent Warmer Control Box X1 w/cable Login
53850 Stoelting Rodent Warmer Control Box X2 w/cable Login
50304 Rectal Thermal Probe Login

All of Stoelting’s Motorized Stereotaxic Instruments are Ultra Precise with 10-micron Resolution (10µm movement)

Stoelting’s Motorized Stereotaxic Manipulator Arms are designed for fast, accurate positioning during stereotaxic surgery. Ideal for inexperienced users, the motorized manipulator arms employ a touchscreen display for easy-to-control movement of each axis. Manual movement available anytime. Optional Drill feature available.

Warmer Ready Base: Stoelting Stereotaxic Instruments are the ONLY stereotaxic instrument on the market with an integrated warming base included on all units! Simply purchase Stoelting’s Rodent Warmer Control Box X1 (item 53800), or Rodent Warmer Control Box X2 (item 53850) to use the warming function.

Stoelting’s Motorized Stereotaxic Manipulator Arms are designed for fast, accurate positioning during stereotaxic surgery. Ideal for inexperienced users, the motorized manipulator arms employ a touchscreen display for easy-to-control movement of each axis. Manual movement available anytime. Optional Drill feature available (51555M).

Warmer Ready Base: Stoelting Stereotaxic Instruments are the ONLY stereotaxic instrument on the market with an integrated warming base included on all units! Simply purchase Stoelting’s Rodent Warmer Control Box X1 (item 53800), or Rodent Warmer Control Box X2 (item 53850) to use the warming function.

Stoelting's Motorized Manipulator Arm Features:

• Automatic motorized movement using touchscreen display
• Various speeds (4mm/s to 0.1mm/s)
• Manual option always available
• Optional Drill feature
• 1µm movement

Electrical Specs:

Power Supply:

Part Number: SD165-24-UD-P5

Input:               100 – 240V – 50 – 60 HZ 1.4A Max

Output :           24V 2.71A

Approvals :      CE, FCC, cULus, ROHS, GS, PSE



LCD Screen Size:

Resolution: 480x272

Color:          Full Color

Touch:        Resistive touch

Motors:

3 high performance stepper Motors

Resolution:  .01 microns.

Routing Offset: 0.05 microns

Maximum Speed: 2.7mm/s

Minimum Speed: 15um/s *D-V Only*



Calibrating Screen:



The screen may become un-calibrated during shipping or over time.

When to Calibrate the Screen:

-        If the buttons are not responding

-        If the screen does not respond to pressing buttons

-        If you have to press down with a lot of pressure



To Calibrate the Screen:

-        Turn off power

-        Press down on the screen with figure anywhere while power if off

-        With figure pressing down on screen turn on power



During bootup the screen detects the PRESS and goes into calibration mode.  During Calibration the screen will display blinking dots one at a time.  Press the MIDDLE of each dot as they appear.  Be careful to make sure you press the middle of each dot.  The screen will go through Calibration 2 times and when complete the screen will return to the home screen.  If you find the calibration unsatisfactory you can always repeat calibration.




Stoelting's Motorized Manipulator Arm Features:
• Automatic motorized movement using touchscreen display
• Various speeds (4mm/s to 0.1mm/s)
• Manual option always available
• Optional Drill feature
• 10µm movement

Motor Speeds:

Motor Speeds

A-P

M-L

D-V

Pause

*2.77 mm/s

YES

YES

YES

NO

*1 mm/s

YES

YES

YES

NO

.5 mm/s

NO

NO

YES

YES

250um/s

NO

NO

YES

YES

160 um/s

YES

YES

NO

YES

100 um/s

NO

NO

YES

YES

75 um/s

NO

NO

YES

YES

50 um/s

NO

NO

YES

YES

25 um/s

NO

NO

YES

YES

15 um/s

NO

NO

YES

YES



Note: * Pause is not an option for speeds highlighted in RED.

Note: These speeds are approximations and will vary a little.



Terms Defined:

A-P          = Anterior – Posterior Axis Coordinate

M-L          = Medial – Lateral Axis Coordinate

D_V         = Dorsal-Ventral  Axis Coordinate

Bregma  = The junction of the sagittal and coronal sutures at the top of the skull (www.freedictionary.com)

Home     = Zero Point of reference

Saved Offset = Distance Value added to axis position when play button is pressed or when Routing mode is engaged.

Routing Resolution = This is the distance the drill will travel each pass until it reaches the D-V offset. The routing resolution is 0.05mm each route.



Routing:

The routing feature is used to cut out a piece of the skull. The D-V routing distance is .05mm each step.  This means that if D-V routing offset is .10mm it will take 2 passes to complete the route.

               Steps:

1: Move the drill to the start position of the routing

2: Press the Keypad button for the A-P.

               A: Press the Clear button

               B: Type in the offset amount

               C: Press the Save button

               D: Press the Hide button.

3: Press the M-L button

               A: Press the Clear Button

               B: Type in the offset amount

               C: Press the Save Button

               D: Press the Hide Button

4: Press the D-V Button

               A: Press the Clear Button

               B: Type in the offset amount – about .20mm to start

               C: Press the save button

5: Turn on Drill by pressing the drill button

6: Set the speed for each axis.

7: Press the Route button.
